ProductFamily | ThinkBook |
Model | 15 |
Number Of Built-in Speakers | 2 |
Speaker Power | 2 W |
Built-in Microphone | Y |
Number Of Microphones | 2 |
Audio System | Dolby Audio |
Battery Technology | Lithium Polymer (LiPo) |
Battery Capacity | 45 Wh |
Battery Life (max) | 6 h |
Fast Charging | Y |
Front Camera | Y |
Front Camera HD Type | Full HD |
Front Camera Resolution | 1920 x 1080 pixels |
Privacy Camera | Y |
Privacy Type | Privacy shutter |
Product Type | Notebook |
Form Factor | Clamshell |
Color Name | Mineral Grey |
Display Diagonal | 15.6" |
Display Resolution | 1920 x 1080 pixels |
HD Type | Full HD |
LED Backlight | Y |
Panel Type | IPS |
Touchscreen | Y |
Native Aspect Ratio | 16:9 |
Anti-glare Screen | Y |
Display Brightness | 300 cd/m² |
RGB Color Space | NTSC |
Color Gamut | 45% |
Contrast Ratio (typical) | 800:1 |
SSD Form Factor | M.2 |
SSD Capacity | 512 GB |
Certification | EPEAT Gold ENERGY STAR 8.0 ErP Lot 3 RoHS compliant TV MIL-STD-810H |
NVMe | Y |
Product Color | Gray |
Housing Material | Polycarbonate (PC), Acrylonitrile butadiene styrene (ABS), Aluminum |
Password Protection | Y |
On-board Graphics Card | Y |
Discrete Graphics Card | N |
Discrete Graphics Card Model | Not available |
On-board Graphics Card Model | Intel Iris Xe Graphics |
Numeric Keypad | Y |
Pointing Device | Touchpad |
Keyboard Layout | QWERTY |
Keyboard Backlit | Y |
Spill-resistant Keyboard | Y |
Keyboard Language | English |
Internal Memory | 16 GB |
Internal Memory Type | DDR4-SDRAM |
Maximum Internal Memory | 40 GB |
Memory Form Factor | On-board + SO-DIMM |
Memory Slots | 1x SO-DIMM |
Memory Clock Speed | 3200 MHz |
Mobile Network Connection | N |
Top Wi-Fi Standard | Wi-Fi 6 (802.11ax) |
Bluetooth | Y |
Wi-Fi Standards | Wi-Fi 6 (802.11ax) |
Antenna Type | 2x2 |
Bluetooth Version | 5.1 |
Ethernet LAN | Y |
Ethernet LAN Data Rates | 100,1000 Mbit/s |
Operating Temperature (T-T) | 5 - 35 °C |
Storage Temperature (T-T) | 5 - 43 °C |
Operating Relative Humidity (H-H) | 8 - 95% |
Storage Relative Humidity (H-H) | 5 - 95% |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A Ports Quantity | 2 |
Combo Headphone/mic Port | Y |
HDMI Ports Quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C Ports Quantity | 1 |
Ethernet LAN (RJ-45) Ports | 1 |
USB Type-C DisplayPort Alternate Mode | Y |
USB Power Delivery | Y |
AC Adapter Power | 65 W |
AC Adapter Frequency | 50 - 60 Hz |
AC Adapter Input Voltage | 100 - 240 V |
Processor Family | Intel® Core™ i7 |
Processor Manufacturer | Intel |
Processor Model | i7-1255U |
Processor Cores | 10 |
Processor Cache | 12 MB |
Configurable TDP-down | 12 W |
Processor Boost Frequency | 4.7 GHz |
Processor Generation | 12th gen Intel® Core™ i7 |
Intel VT-x With Extended Page Tables (EPT) | Y |
Execute Disable Bit | Y |
CPU Configuration (max) | 1 |
Embedded Options Available | N |
Intel Virtualization Technology For Directed I/O (VT-d) | Y |
Intel Virtualization Technology (VT-x) | Y |
Intel Flex Memory Access | Y |
Intel Trusted Execution Technology | Y |
Trusted Platform Module (TPM) | Y |
Fingerprint Reader | Y |
Cable Lock Slot | Y |
Cable Lock Slot Type | Kensington |
Password Protection Type | Power on, Supervisor, HDD |
Trusted Platform Module (TPM) Version | 2.0 |
Operating System Installed | Windows 11 Pro |
Operating System Architecture | 64-bit |
Total Storage Capacity | 512 GB |
Storage Media | SSD |
Optical Drive Type | N |
Card Reader Integrated | Y |
Compatible Memory Cards | MMC, SDXC, SD, SDHC |
Number Of SSDs Installed | 1 |
Total SSDs Capacity | 512 GB |
SSD Interface | PCI Express 3.0 |
Memory Channels | Dual-channel |
Intel Thunderbolt 4 | Y |
Thunderbolt 4 Ports Quantity | 1 |
Audio Chip | Realtek ALC3287 |
Fast Charging Time (50%) | 30 min |
Maximum Shipping Altitude | 120000" (3048 m) |
USB Sleep-and-Charge | Y |
USB Sleep-and-Charge Ports | 1 |
Operating System Language | English |
| |
